Installation of the air-conditioning unit Installation instructions REVO-E
30
4.3. Applying the adhesive
The equipment must be secured firmly against crashing during
work under suspended loads.
1. Free the Armaflex frame with compressed air from dust and dirt.
2. The adhesive bead must be applied in the middle of the Armaflex
frame.
3.1. Fig. 12: Applying the adhesive bead to the Armaflex frame.
3.2. Fig. 13: Applying the adhesive bead onto the marked area of the
roof. Apply marking using a template.
3.3. Fig. 14: The screw-on / support points of the compressor pan are
provided with adhesive.
Figure 12:
Warning!
Danger of injuries due to air-
conditioning unit or components
of it crashing down accidentally!
Figure 13:
Figure 14:
