5 Connecting the air-conditioning unit
5.1. Electrical connections
The safety regulations in section 2 of this Installation instructions
regarding the work on the electrical system must be complied with.
The electrical hook-up is to be done according to the following figures.
Item 1 +24 V-
Item 2 -24 V-
Warning!
High voltage!
Warning
Danger to life
Figure 17:
