Valley Rainger Linear - Linear Water Application Data

42 Rainger Linear
OPERATION
Wheel Rotation Speeds
Center Drive
Output RPM
High Float
14.9 x 24
Maxi-Float
16.9 x 24
29 6.54 ft/min 6.98 ft/min
30 6.77 ft/min 7.22 ft/min
35 7.90 ft/min 8.42 ft/min
37 8.35 ft/min 8.90 ft/min
56 12.63 ft/min 13.48 ft/min
58 13.08 ft/min 13.96 ft/min
68 15.34 ft/min 16.36 ft/min
69 15.56 ft/min 16.60 ft/min
*Machine speed is controlled by the speed of the end drive units.
Linear Water Application Data
*
EXAMPLE
Application/Rate
=
GPM x 2310
=
1100 x 2310
=
2,541,000
=
0.48 ft
(In /Day/Capac.) Acres x 43560 120 x 43560 5,227,200 Day
Application/Rate
=
GPM x 2310
=
( ) x 2310
=
( )
=
( )
(In /Day/Capac.) Acres x 43560 ( ) x 43560 ( ) Day
EXAMPLE
Hours/Pass
=
Length of Run
=
3234 ft
=
9.1 hours
@ 100% 60 x Chart Speed 60 x 5.90 Pass
Hours/Pass
=
Length of Run
=
( )
=
( )
@ 100% 60 x Chart Speed 60 x ( ) Pass
Add maintenance, refueling, and other “down time” to the calculated results.
EXAMPLE
Inches/Pass
=
Hrs /Pass x App. Rate (In Day)
=
9.1 x 0.48
=
0.18 ft
@ 100% 24 24 Pass
Inches/Pass
=
Hrs /Pass x App. Rate (In Day)
=
( )
=
( )
@ 100% 24 24 Pass
Hrs./Pass
100% @ 100% Hours/Pass
90% _________ ÷ 0.90 = _________
80% _________ ÷ 0.80 = _________
70% _________ ÷ 0.70 = _________
60% _________ ÷ 0.60 = _________
50% _________ ÷ 0.50 = _________
40% _________ ÷ 0.40 = _________
30% _________ ÷ 0.30 = _________
25% _________ ÷ 0.25 = _________
20% _________ ÷ 0.20 = _________
15% _________ ÷ 0.15 = _________
10% _________ ÷ 0.10 = _________
5% _________ ÷ 0.05 = _________
Inches/Pass
100% @ 100% In/Pass
90% _________ ÷ 0.90 = _________
80% _________ ÷ 0.80 = _________
70% _________ ÷ 0.70 = _________
60% _________ ÷ 0.60 = _________
50% _________ ÷ 0.50 = _________
40% _________ ÷ 0.40 = _________
30% _________ ÷ 0.30 = _________
25% _________ ÷ 0.25 = _________
20% _________ ÷ 0.20 = _________
15% _________ ÷ 0.15 = _________
10% _________ ÷ 0.10 = _________
5% _________ ÷ 0.05 = _________
Percentage Timer Settings
