Valley Rainger Linear - TROUBLESHOOTING; In-Line Shut Down Issues

Rainger Linear 97
TROUBLESHOOTING
IN-LINE SHUT DOWN
WILL THE CONTROL PANEL COME
ON?
YES
NO
CALL VALLEY DEALER
IS THERE INCOMING POWER TO
CONTROL PANEL?
YES
NO
DID THIS CORRECT THE
PROBLEM?
NO
ARE THE END TOWER WHEELS
STUCK IN WHEEL TRACK?
IS THERE A FLAT TIRE ON END
TOWER?
IS THERE U-JOINT FAILURE ON END
TOWER?
DID THE OVER WATERING TIMER,
TIME OUT?
IS WATER PRESSURE LOW?
NO
YES
IS THERE A GEAR BOX FAILURE ON
END TOWER?
NO
YES
DID THIS CORRECT THE
PROBLEM?
NO
YES
REPAIR OR REPLACE
GEAR BOX
DID THIS CORRECT THE
PROBLEM?
NO
YES
DETERMINE AND
CORRECT THE CAUSE
OF LOW WATER
PRESSURE
NO
YES
DID THIS CORRECT THE
PROBLEM?
NO
YES
REVERSE DIRECTION
OF MACHINE TO RESET
TIMER
NO
YES
DID THIS CORRECT THE
PROBLEM?
NO
YES
REPAIR U-JOINT
NO
YES
DID THIS CORRECT THE
PROBLEM?
NO
YES
REPAIR TIRE
NO
YES
DID THIS CORRECT THE
PROBLEM?
NO
YES
FILL IN WHEEL TRACK
WITH DRY SOIL
YES
REPAIR GENERATOR
CALL VALLEY DEALER
In-Line Shut Down
In-line shut downs typically occur because of a failure in one or more of the following areas: power source,
machine controls, or end tower. Use the flow chart below to determine if the in-line shut down was due to a
mechanical failure. Refer to the operation pages of this section or the control panel Owners Manual for other
TROUBLESHOOTING information.
DIRECTION OF
TRAVEL
CALL PUBLIC POWER
COMPANY
OR
