Rainger Linear 91
MAINTENANCE
Span Flushing Procedure
8. If the machine is equipped with an end gun:
• Make sure the booster pump hose drain is not
plugged with sand or debris and the hose is
completely drained. See Figure 91-1.
• Clean the end gun shut off solenoid valve
cross filter or optional dirty water filter. See
Figures 91-2 and 91-3.
• Clean the water shut off valve external filter.
See Figure 91-4.
1
Figure 91-1 1. Booster Pump Hose Drain
1
Figure 91-2 1. Cross Filter
1
Figure 91-3 1. Optional Dirty Water Filter
1
2
Figure 91-4 1. Water Shut Off Valve
2. External Filter
