Rainger Linear 95
MAINTENANCE
Drive Unit
Pre
season
1st
Pass
4th
Pass
Mid
season
Post
season
Remarks
Check the water and flex joint hose for
leaks.
X X Tighten clamps or replace as required.
Check the motor lead cable for dam-
age.
X X Replace if outer insulating sheath is
cracked.
Check for proper ground connection
on motor and motor lead.
X X
Check the motor drain hole for proper
drainage.
X X
Check the center drive gearbox lubri-
cant and drain moisture.
X X See the CENTER DRIVE GEARBOX in
the MAINTENANCE SECTION.
Change the center drive gear box lubri-
cant.
X Change after the first season and then
change every third season thereafter.
Check the center drive gearbox seals
and gaskets.
X
Check the wheel gearbox lubricant
level and drain moisture.
X X See the WHEEL GEARBOXES in the
MAINTENANCE SECTION.
Change the wheel gearbox lubricant. X Change after the first season and then
change every third season thereafter.
Check the drive shaft U-joints. X
Check the U-joint and drive shaft cov-
ers for damage.
X Replace as required.
Check the wheel lug nut torque. X X Tighten to 125 ft lb (169 N·m) torque.
Check the tire pressure. X X X See the TIRE PRESSURES in the MAIN-
TENANCE SECTION.
Clean the wheel gearbox vent hole in
expansion chamber.
X X X X Vent hole must be kept open to extend the
wheel gearbox seal life.
Check the ARAS/EOFS arms for
proper operation.
X X
Overhang, End Gun and Booster Pump
Pre
season
1st
Pass
4th
Pass
Mid
season
Post
season
Remarks
Check overhang cables for broken ca-
ble strands.
X X
Check the end gun drain. X X X Clean as required.
Check the sand trap. X X Clean as required.
Check the end gun arc settings. X X Refer to sprinkler chart.
Check the end gun bearing and brake. X X
Check the end gun nozzle for wear. X
Drain the booster pump and booster
pump hose.
X See WINTERIZATION in MAINTENANCE
SECTION.
Recommended Maintenance
