CONTENTS
Section Heading Page
INSTALLER GUIDE 4 - 46
OWNER GUIDE 47 - 59
1. SAFETY 7
2. APPLIANCE DATA, EFFICIENCY AND NOx 8
2.1 General information. 8
2.2 Efficiency. 9
3. LIST OF AVAILABLE KITS 9
4. APPLIANCE AND RECESS DIMENSIONS 10
5. GENERAL INSTALLATION REQUIREMENTS 12
5.1 Regulations, Standards and Law. 12
5.1.1 Considerations for timber framed buildings. 12
5.2 Ventilation requirements. 12
5.3 Fireguard requirements. 13
5.4 Room considerations. 13
5.5 Fireplace preparation. 13
5.6 The surround. 13
5.7 Hearth / plinth requirements. 14
5.8 Fireplace clearances. 15
5.9 Installation options. 16
5.10 Terminal guard and terminal clearances. 16
6. UNPACKING AND PRELIMINARY CHECKS 18
6.1 Unpacking. 18
6.2 Appliance disassembly. 19
6.3 Preliminary checks. 20
7. GAS SUPPLY CONNECTION 21
8. WALL PREPARATION 22
8.1 Select appliance position. 22
8.2 Constructing a recessed opening. 22
8.2.1 Fitting a lintel. 22
8.2.2 Preparing a wall cavity. 23
8.3 Combustible wall materials. 23
8.4 Cutting the flue hole for brick, stone etc. building. 24
8.5 Cutting the flue hole in timber frame buildings. 24
8.6 Prepare appliance fixing holes. 26
