Page 18
© GDC Group Ltd. 2013
4. PACK CONTENTS
The items required for this appliance are packed in sections.
Section 1 - Fire unit contains:
1 Convection box and burner assembly
1 Loose parts pack including: -
1 Grommet for rear of convection box
1 Strip of floor sealing tape
1 Flue restrictor
4 Fibre plugs
4 Woodscrews
2 Fire retaining cables
2 Cable adjusters
2 Eyebolts
1 Length of self-adhesive foam seal
1 Inlet “T” connector including pressure test point, nut and olive for 8mm inlet pipe.
1 Burner tray trim.
1 Control position label for Dream and Eternal.
1 Battery
1 Ceramic fuel effect pack (Not shown)
2 No.8 x 3/8 screws (Black) for securing the flue restrictor.
2 No.8 x 3/8 screws (Black) for securing the fascia.
4 No.8 x 3/8 screws (Black) for securing the Dream hood.
3 No.8 x 3/8 screws (Black) for securing the Obsession outlet baffle.
1 Knurled screw for slider linkage.
2 M5 x 10 countersunk screws for securing the slider control to the Dream fascia.
4 M4 x 10 screws for securing the infill trims to the Dream fascia.
Section 2 - Fire front contains
1 Firefront casting
1 Front cover casting.
1 Fascia
1 Set of infill trims (Dream, Masquerade and Excelsior models)
1 Slider control (Dream, Masquerade and Excelsior models)
1 Hood (Dream, Masquerade and Excelsior models)
Remove all the items carefully to prevent damage. Take special care when handling
the ceramic components. Some items may be contained in the packaging fitments -
Examine the packaging carefully before discarding. Check that all the items are
present and undamaged.
INSTALLER GUIDE
