This product uses fuel effect pieces, burner
compartment walls and gaskets containing
Refractory Ceramic Fibres (RCF), which are man-
made vitreous silicate fibres. Excessive exposure
to these materials may cause temporary irritation
to eyes, skin and respiratory tract. Consequently,
it makes sense to take care when handling these
articles to ensure that the release of dust is kept
to a minimum. To ensure that the release of
fibres from these RCF articles is kept to a
minimum, during installation and servicing we
recommend that you use a HEPA filtered vacuum
to remove any dust and soot accumulated in and
around the fire before and after working on the
fire. When replacing these articles we
recommend that the replaced items are not
broken up, but are sealed within a heavy duty
polythene bag, clearly labelled as RCF waste.
This is not classified as “hazardous waste” and
may be disposed of at a tipping site licensed for
the disposal of industrial waste.
Protective clothing is not required when handling
these articles, but we recommend you follow the
normal hygiene rules of not smoking, eating or
drinking in the work area and always wash your
hands before eating or drinking.
This appliance does not contain any component
manufactured from asbestos or asbestos related
products.
The appliance data label is on a tie below the
burner and is visible when the bottom front
cover is removed.
Gas: Natural (G20) Propane (G31)*
Inlet Pressure 20mbar 37mbar
Input - Max. (Gross) 6.85kW (23,400 Btu/h) 6.7kW (22,860 Btu/h)
Input - Min. (Gross) 2.7kW (9,410 Btu/h) 4.3kW (14,670 Btu/h)
Output - Max. 4.2kW (14,300 Btu/h) 4.1kW (13,900 Btu/h)
Output - Min. 1.3kW (4,440 Btu/h) 2.0kW (6,820 Btu/h)
Burner Test Pressure (Cold) 17.3±0.75mbar 35.1±0.75mbar
(7.0±0.3in w.g.) (14.1±0.3in w.g.)
Gas Connection 8mm pipe 8mm pipe
Burner Injector Bray Cat. 31 Size 440 Bray Cat. 18 Size 180
Pilot & Atmosphere
Sensing Device SIT Ref. OP9030 SIT Ref. OPLPG9222
Ignition Electronic (Battery 9V PP3) Electronic (Battery 9V PP3)
Aeration Non-adjustable Non-adjustable
*When converted using kit 591159
2.1 The installation must be in accordance with
these instructions.For the user’s protection,
in the United Kingdom it is the law that all
gas appliances are installed by competent
persons in accordance with the current
edition of the Gas Safety (Installation and
Use) Regulations. Failure to install the
appliance correctly could lead to
prosecution. The Council for the
Registration of Gas Installers (CORGI)
requires its members to work to recognised
standards.In the United Kingdom the
installation must also be in accordance with:
a) All the relevant parts of local regulations.
b) The current edition of the Building
Regulations issued by the Department of the
Environment and the Welsh Office or the
Building Standards (Scotland)
(Consolidation) Regulations issued by the
Scottish Development Department.
c) All relevant codes of practice.
d) The relevant parts of the current editions
of the following British Standards:-
BS 715
BS 1251
BS 1289 Part 1
BS 1289 Part 2
BS 4543 Part 2
BS 5440 Part 1
BS 5440 Part 2
BS 5871 Part 2
BS 6461 Part 1
BS 6891
BS 8303
In the republic of Ireland the installation
must also conform to the relevant parts of:
a) The current edition of IS 813
b)All relevant national and local rules in
force.
Page 4
1.APPLIANCE DATA
INSTALLER GUIDE
2. GENERAL INSTALLATION
REQUIREMENTS
