Valtra Q Series User Manual

1. Memory button 1
2. Memory button 2
3. Road speed range (B, +)
4. Field speed range (A, - )
5. Rear lift (AutoControl): Lift / Stop / Lower / Float switch
6. Hydraulics fingertip lever 1
7. Hydraulics fingertip lever 2
8. Power shuttle switch
9. Max. speed / cruise adjustment
SIDE PANEL
DRIVE
LEVER
1. Phone holder
2. Emergency brake
3. 3-pin current socket
4. 3-pin current socket (optional)
5. SmartTouch Extend connector (optional)
6. ISOBUS terminal connector (optional)
7. Implement signal connector
8. Button for fuel-operated heater (optional)
9. Double USB port (quick charge) (optional)
10. 2-pin current socket
11. Power switch for 2-pin current socket
12. 2-pin current socket (controlled with power switch)
13. Power outlet
14. Trailer hitch release lever (optional)
1
1
2
3
4
5
6
7
12
11
13
8
9
10
2
3
4
5
6
7
8
9
14
5
Q Series Quick Guide
