IMPORTANT: The maximum allowed input torque for the front PTO gearbox is
759 Nm and the nominal is 692 Nm. If the tractor is equipped with the LHLink or
the pivoting front linkage, the maximum allowed input torque for the front PTO
gearbox is 732 Nm and the nominal is 549 Nm.
IMPORTANT: Always make sure that the cardan shaft does not touch the
hydraulic connectors at any working position.
3.19.3.1 Activating and deactivating front power take-off
The front power take-off (PTO) switch is spring-returned and has two positions,
on and off.
GUID-F7B9F363-591D-4D78-B17B-646646A58744
1. Switch for front PTO
• Start the front PTO by pressing down the switch for front PTO and pulling it
backward.
• Deactivate the front PTO by pressing down the switch for front PTO and
pushing it forward.
3.20 U-Pilot headland automatics
The aim of the U-Pilot headland automatics is to automate a group of often used
functions. A typical example is a headland turn.
The idea of the U-Pilot is that the operator runs the whole operational cycle
activating the required functions. The functions activated and the travelled
3. Operation
- 279 -
