5.4 Viewing service codes
You can read active service codes on the tractor terminal display.
If there is an active service code, the book symbol flashes on the display.
1. If the tractor terminal main menu is not displayed, press ESC button as many
times as needed.
2. Press the down arrow four times.
The service codes are displayed on the display.
123456--04--040
123456--04--040
123456--04--040
123456--04--040
123456--04--040
GUID-4394CED9-E471-4778-A7BA-5ED1765B5729
3. Browse the service code list.
To browse the service code list, use the arrow buttons.
If arrows are shown in the display margins, you can browse through more
codes by pressing the corresponding arrow button.
4. Exit the service code list.
With a short press of the ESC button you can return to the main menu. A
long press of the ESC button returns to the previously active drive display.
5.5 Viewing the IO list
In a fault situation, you can give detailed information of the tractor to the service
personnel by viewing the tractor IO list on tractor terminal display.
1. If the tractor terminal main menu is not displayed, press ESC button as many
times as needed.
2. Press the down arrow three times to navigate to the menu 3.
3. Press the right arrow to enter the IO list view.
A list of control units is displayed on the display.
Unit 3
Unit 4
Unit 0
Unit 5
Unit 34
I/O
GUID-A28DC31E-8F39-4A62-A271-13E75860BD9A
5. Troubleshooting
- 475 -
