Page #22 background imageLoading...
Page #22 background image
LTCA-10/LTCA-40 USER’S MANUAL
22
NOTE
The LTCA-10/40 will calculate the equivalent resistance value at this new
temperature.
h. The following “WARNING” screen will be displayed:
This warning reminds the operator that the next sequence of test steps will run current
through the test load.
Press the
[ENTER] key to proceed to the next step.
i. One of the following menus will be displayed (with the relevant test current value)
depending on how many channels were selected in step c.
V1 Test Only V1 & V2 Test
V1, V2, & V3 Test
If you have made any errors or would like to abort the test, press the
[STOP] key, and
you will be returned to the “START-UP” menu.
Press the [START] key to run the test. The following screen will be displayed
momentarily:
After the LTCA-10/40 finishes its internal calibration, the “XFMR CHARGING” screen
will be displayed:
XFMR CHARGING
PLEASE WAIT...
* XFMR ENERGIZED! *
CALIBRATING
PLEASE WAIT…
-V1, V2, & V3 TEST-
1 AMP TEST
“START” TO RUN TEST
OR
“STOP” TO ABORT
-V1 & V2 TEST-
1 AMP TEST
“START” TO RUN TEST
OR
“STOP” TO ABORT
-V1 TEST ONLY-
1 AMP TEST
“START” TO RUN TEST
OR
“STOP” TO ABORT
*********WARNING*********
DANGEROUS FLASH-OVER
WILL OCCUR IF CABLES
ARE DISCONNECTED!
*************************
