7. Install the air intake grille (E, Figure 23) and attach with the fastener(s) (D
After a period of time, debris can collect in the cylinder cooling fins and cause the engine
to overheat. This debris cannot be removed without partial disassembly of the engine.
Have a Briggs & Stratton Authorized Dealer inspect and clean the air cooling system as
recommended in the Maintenance Schedule.
Storage
Fuel System
Refer to Figure: 24.
WARNING
Fuel and its vapors are flammable and explosive. Fire or explosion could result in
burns or death.
Fuel Storage
• Because pilot lights or other ignition sources can cause explosions, keep fuel or
equipment away from furnaces, stoves, water heaters or other appliances that
have pilot lights.
Keep the engine level (normal operating position). Fill the fuel tank (A, Figure 24) with
fuel. For fuel expansion, do not fill above the fuel tank neck (B).
Fuel can become stale when kept in a storage container for more than 30 days.The use
of analcohol-free fuel stabilizer and ethanol treatmentin the fuel storage container is
recommended to prevent fuel degradation and keep the fuel fresh.
When you fill the fuel container with fuel, addan alcohol-free fuel stabilizer as specified
by the manufacturer’s instructions.If gasoline in the engine has not been treated with a
fuel stabilizer, it must be drained into an approved container.Operate the engine until it
is out of fuel.
Engine Oil
While the engine is still warm, change the engine oil. Refer to Change the Engine Oil
section.
Troubleshooting
Assistance
For assistance, contact your local dealer or go to BRIGGSandSTRATTON.COM or call
1-800-444-7774 (in USA).
Specifications
Specifications andService Parts
MODELS: 490000, 49E700, 49E800
Displacement 49.42 ci ( 810 cc)
Bore 3.300 in (83,81 mm)
Stroke 2.890 in (73,41 mm)
Oil Capacity 66 - 68 oz (1,9 - 2,0 L)
Spark Plug Gap .030 in (,76 mm)
Spark Plug Torque 180 lb-in (180 Nm)
Armature Air Gap .008 - .012 in (,20 - ,30 mm)
Intake Valve Clearance .004 - .006 in (,10 - ,15 mm)
Exhaust Valve Clearance .004 - .006 in (,10 - ,15 mm)
Engine power will decrease 3.5% for each 1,000 feet (300 meters) above sea level
and 1% for each 10°F (5.6°C) above 77°F (25°C). The engine will operate satisfactorily
at an angle up to 15°. Refer to the equipment operator's manual for safe permitted
operating limits on slopes.
MODELS: 490000, 49E700, 49E800
Service Part Part Number
Cyclonic Air Filter 841497
Cyclonic Safety Filter 821136
Low Profile Air Filter 796031
Air Filter Pre-cleaner 797704
Oil - SAE 30 100028
Fuel Filter 84001895
Resistor Spark Plug 491055S
Long Life Platinum Spark Plug 5066K
Spark Plug Wrench 19576S
MODELS: 490000, 49E700, 49E800
Spark Tester 84003327
We recommend that you see a Briggs & Stratton Authorized Dealer for all maintenance
and servicing of the engine and engine parts.
Power Ratings
The gross power rating for individual gasoline engine models is labeled in accordance
with SAE (Society of Automotive Engineers) code J1940 Small Engine Power & Torque
Rating Procedure, and is rated in accordance with SAE J1995. Torque values are
derived at 2600 RPM for those engines with “rpm” called out on the label and 3060 RPM
for all others; horsepower values are derived at 3600 RPM. The gross power curves
can be viewed at www.BRIGGSandSTRATTON.COM. Net power values are taken with
exhaust and air cleaner installed whereas gross power values are collected without
these attachments. Actual gross engine power will be higher than net engine power and
is affected by, among other things, ambient operating conditions and engine-to-engine
variability. Given the wide array of products on which engines are placed, the gasoline
engine may not develop the rated gross power when used in a given piece of power
equipment. This difference is due to a variety of factors including, but not limited to, the
variety of engine components (air cleaner, exhaust, charging, cooling, carburetor, fuel
pump, etc.), application limitations, ambient operating conditions (temperature, humidity,
altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations,
Briggs & Stratton may substitute an engine of higher rated power for this engine.
Warranty
Briggs & Stratton
®
Engine Warranty
Effective August 2022
Limited Warranty
Briggs & Stratton warrants that, during the warranty period specified below, it will
repair or replace, free of charge, with a new, reconditioned or re-manufactured part,
at the sole discretion of Briggs & Stratton, any part that is defective in material or
workmanship or both. Transportation charges on product submitted for repair or
replacement under this warranty must be borne by purchaser. This warranty is effective
for and is subject to the time periods and conditions stated below. For warranty
service, find the nearest Authorized Service Dealer in our dealer locator map at
BRIGGSandSTRATTON.COM. The purchaser must contact the Authorized Service
Dealer, and then make the product available to the Authorized Service Dealer for
inspection and testing.
There is no other express warranty. Implied warranties, including those of
merchantability and fitness for a particular purpose, are limited to one year
from purchase, or to the extent permitted by law. All other implied warranties
are excluded. Liability for incidental or consequential damages are excluded
to the extent exclusion is permitted by law. Some states or countries do not allow
limitations on how long an implied warranty lasts, and some states or countries donot
allow the exclusion or limitation of incidental or consequential damages, so the above
limitation and exclusion may not apply to you. This warranty gives you specific legal
rights and you may also have other rights which vary from state to state and country to
country
*
.
Standard Warranty Terms
1, 2
Vanguard
®
; Commercial Series
Consumer Use - 36 months
Commercial Use - 36 months
XR Series
Consumer Use - 24 months
Commercial Use - 24 months
All Other Engines Featuring Dura-Bore™ Cast Iron Sleeve
Consumer Use - 24 months
Commercial Use - 12 months
All Other Engines
Consumer Use - 24 months
Commercial Use - 3 months
1
These are our standard warranty terms, but occasionally there may be additional
warranty coverage that was not determined at time of publication. For a listing of
current warranty terms for your engine, go to BRIGGSandSTRATTON.COM or contact
your Briggs & Stratton Authorized Service Dealer.
2
There is no warranty for engines on equipment used for prime power in place of a
utility; standby generators used for commercial purposes, utility vehicles exceeding 25
MPH, or engines used in competitive racing or on commercial or rental tracks.
*
In Australia - Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable loss or damage.
11
