OPERATION : DMX OPERATION
3
02.9663.0001 B 11-Jun-02 33
* Dimmer refers to either an external dimmer for VL1000TS models or an internal dimmer
for VL1000AS models. Regardless, this channel must be included for both profiles.
Table 3-2: Enhanced 16-Bit Mode – Models VL1000 TS/AS
DMX Channel Parameter Range
1 Dimmer * 0-255
2 Hi Byte Pan 0-65535
3 Lo Byte Pan 0-65535
4 Hi Byte Tilt 0-65535
5 Lo Byte Tilt 0-65535
6 Edge 0-255
7 Zoom 0 (small) - 255 (big)
8 Diffusion 0 (open) - 255 (diffused)
9 Blue 0 (open) - 255 (full saturation)
10 Amber 0 (open) - 255 (full saturation)
11 Magenta 0 (open) - 255 (full saturation)
12 Rotating Gobo 0-127 index
128-255 rotate
13-14 Gobo Index
(13 = Hi Byte)
(14 = Lo Byte)
Index:
0-65535
Rotate:
0 (cw max) - 32599 (cw min)
32600-33047 (stop)
33048 (ccw min) - 65535 (ccw max)
15 Frame 1A 0 (open) - 255 (closed)
16 Frame 1B 0 (open) - 255 (closed)
17 Frame 2A 0 (open) - 255 (closed)
18 Frame 2B 0 (open) - 255 (closed)
19 Frame 3A 0 (open) - 255 (closed)
20 Frame 3B 0 (open) - 255 (closed)
21 Frame 4A 0 (open) - 255 (closed)
22 Frame 4B 0 (open) - 255 (closed)
23 Rotate Frame 0-255
128 center
24 Focus Time 0-255
25 Color Time 0-255
26 Beam Time 0-255
27 Control 0-255
