OPERATION : DMX MAPPING
3
02.9663.0001 B 11-Jun-02 37
Rotating Gobo Wheel
The function operates in two modes: INDEX Mode and ROTATE Mode. The DMX
values corresponding to these modes are as follows:
• DMX values 0-127 will select each gobo in Indexing mode.
• DMX values 128-255 will select each gobo in Rotating mode.
Index/Rotation
The Gobo Index function utilizes 16-bit control which offers enhanced resolution
whether in INDEX or ROTATE mode.
Table 3-7: DMX Map for Gobo Index/Rotate
Position Indexing Rotating Function
1 0 128 Open
218 146Gobo 1
341 169Gobo 2
463 191Gobo 3
586 214Gobo 4
6 108 236 Gobo 5
Table 3-8: Index/Rotation Range
Function Range
Index 0-65535
Rotate 0 (cw max) - 32599 (cw min)
32600-33047 (stop)
