OPERATION : DMX OPERATION
3
02.9663.0001 B 11-Jun-02 35
DMX Data Display
The DMX data display shows the data received for the given luminaire and does not
show the entire stream of 512 bytes. It shows only the number of channels used for the
given luminaire model in 16-bit enhanced mode.
For example, a VL1000TS luminaire with an address of 40 will show DMX Channels
1-27 which would correlate to DMX Channels 40-66.
