DMX Mapping
Color Mixing
The color mixing mechanism is a CYM subtractive color mixing system made up of a
graduated color system for cyan, yellow, and magenta.
Table 3-4: DMX Map for Cyan
% Value DMX Value Action
0 0 Open
100 255 Closed or Full Saturation
Table 3-5: DMX Map for Yellow
% Value DMX Value Action
0 0 Open
100 255 Closed or Full Saturation
Table 3-6: DMX Map for Magenta
% Value DMX Value Action
0 0 Open
100 255 Closed or Full Saturation
