VARI❋LITE® - VL1000™ ERS LUMINAIRE USER’S MANUAL
72 11-Jun-02 02.9663.0001 B
Operational
Power Requirements
Depending on voltage, 1 to 2 Amps are supplied to Incandescent models through
standard AC distribution while 3 to 9 Amps are supplied to Arc luminaires and ballast.
Operational Temperature
-20° to 122°F (-29° to 50°C)
Cooling
Free convention cooling when hung. Shutter models and floor mounting units
activate a low noise, forced-air cooling system.
Control
Compatible with a wide variety of DMX512 consoles.
Mounting Position
All models can be mounted and operated in any orientation.
Weight
60 lbs (27 kg)
Spacing
Hangs on 26.5 in. (67.3 cm) centers.
26"
(66cm)
26.5"
(67.3cm)
34.5"
(87.6cm)
17.5"
(44.5cm)
