VARI❋LITE® - VL1000™ ERS LUMINAIRE USER’S MANUAL
74 11-Jun-02 02.9663.0001 B
Arc Ballast Unit (Arc Models Only)
Input
Voltage Range
90V to 275V, auto-ranging.
Frequency
50 Hz or 60 Hz
Current Range
2.7 A to 9.0 A*
Power Factor
+/- .97
Output
Open Circuit Voltage
+/- 450V
Lamp Voltage
100V*
Lamp Current
6.25 A*
Lamp Power
625 W*
Output Current Shape
Square wave
Output Frequency
200 Hz*
High Frequency Ripple Current
+/- 3%
* Nominal Values
Weight and Dimensions
Mounting Position
Ballast can be mounted in any orientation.
Weight
16.6 lbs (7.52 kg)
4.54"
(11.5 cm)
13.43"
(34.1 cm)
11.56"
(29.4 cm)
