26 INSPECTION/ CLEANING FANS
Once every four years
• De-energize the unit.
• sassemble the metal front panel as described in the reversibility
section.
• Remove the 10 screws and disassemble the EPP door panel.
• Pull the heat exchanger out of the ventilation unit by pulling the strap,
never remove this strap!
• Remove the supply and exhaust fan from the unit
For the exhaust fan:
- Remove the EPP insert out of - Slide the entire by-pass
the appliance module to the bottom according
the direction of the arrow
.
INSPECTION /
CLEANING
VENTILATORS
0D[1P
1.
2.
