Vatech A9 User Manual

4. Imaging System Overview
vatech A9 (Model name: PHT-30CSS) User Manual 35
English
4.7.4 Enclosed Components
The enclosed components can be disassembled and cleaned. All enclosed
components that are used to support the patient (the Bite, the Chinrest, and the Ear
Rods) should be cleaned with a non-alcohol-based, non-corrosive cleaning solution
and wiped with clean towels.
Components Name and Function Materials
Normal Bite
- For PANO and CBCT normal patients
PC
(Polycarbonate)
Deep Bite Block
*. Deep Bite Block is only available in some
Asian countries.
PC
(Polycarbonate)
Special Bite A
- For PANO TMJ LAT and Sinus PA modes
PC
(Polycarbonate)
Special Bite B
- For PANO TMJ PA and Sinus LAT modes.
PC
(Polycarbonate)
Edentulous
- For PANO edentulous patients
PC
(Polycarbonate)
Third Molar Bite
*. The Third Molar Bite is only available in
some Asian countries and Mexico.
ABS (Acrylonitrile
butadiene
styrene)
copolymer
Special Chinrest
ABS (Acrylonitrile
butadiene
styrene)
copolymer
Normal Chinrest
ABS (Acrylonitrile
butadiene
styrene)
copolymer
Ear Rods (1 set) Silicone
Nasal Positioner Cover
- For CEPH
Silicone
