3. Operation
EzRay Air (Model: VEX-P300) User Manual 15
ENGLISH
Auto Mode
1. When the Auto Mode is turned on by pressing AUTO, the default angle is
displayed as shown in the following figure.
To set the starting point (0°) during exposure, press SET.
2. Select the patient type by turning the jog dial.
3. Perform patient positioning, and press SET.
To check how to perform the patient positioning, refer to ‘4.3 Positioning’ on page
17. The following figure is an example of the maxilla incisor.
