3. Operation
20 EzRay Air (Model: VEX-P300) User Manual
Here are the specific angulations and directions for the tube head in order to take the
best images of a particular tooth (i.e. Bisected angle technique).
Position the receptor carefully not to damage the soft tissue of the
patient’s intra-oral area.
Maxillary Incisor
X-ray beam is directed downward at 45°.
Teeth Angle of inclination
Incisor Maxilla +45˚
