3. Before Installing the System
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 23
English
3.3 Unpacking Boxes
▪ All packaging and Styrofoam used to ship this equipment
are recyclable.
▪ Return the packaging to VATECH representatives or
dispose of it in compliance with the legal regulations of
your country.
3.3.1 Box No. 1 - Main Box
Component
Size (mm / inch)
Weight (kg / lbs.)
▪ Column and Rotating
Unit Assembly
▪ Accessories and Parts
▪ PC System (Optional)
▪ Monitor (Optional)
1,710 (L) x 680 (W) x 1,100 (H) /
67" (L) x 27" (W) x 43" (H)
145 / 320
<Main Box>
