4. Installing the Equipment: Base Stand (Optional)
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 39
English
4.2 Assembling the Base with the Column Unit
If the installation site is a concrete floor, go to section 4.5
Fixing the base (Optional) and do number 1 first, after that
turn back 4.2 Assembling the Base with the Column Unit.
1. Hang the base unit onto two bolts temporarily as shown below.
An installer should hold the base unit to keep it from falling.
