4. Installing the Equipment: Base Stand (Optional)
64 PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
4.11 Tightening the Bolts
1. Tighten the joint bracket bolts.
Allen Wrench
6 mm / 0.24”
Monkey Wrench
n/a
