4. Installing the Equipment: Base Stand (Optional)
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 55
English
4.8 Connecting the Cables to the Equipment.
1. Connect the cables in the back of the column as shown in the figure.
Optic Cable
Cable No.
H002040A
(Part No. 21)
Cable Tie
(Part No. 20)
