PaX-i3D Green (PHT-60CFO) User Manual
113
8 Acquiring CT Images
The FOV size is determined by the CT sensor attached on
the equipment.
A. Select the FOV size for the CT.
B. Select the ROI to be captured under VERTICAL POSITION and
HORIZONTAL POSITION. Once you have selected an FOV size and ROI
(Region of Interest) to capture, the area of the selected FOV and position of
ROI will be viewed on the guidance image. For the FOV 50 X 50, you may
select a specic tooth position to be captured on the full arch guidance image.
C. Select the image quality mode
D. Select the voxel resolution
E. If
Metal Artifact Reduction
is necessary, click
Apply
under
Metal Artifact
Reduction
. Metal Artifact Reduction reduces the appearance of metal in
imaging. This function is most effective when there are fewer than 3 metal
artifacts.
The MAR (Metal Artifact Reduction) function doubles image
reconstruction time.
H F G
C
D
E
