40
Fuse Protected circuit
F10 (7.5 A) Instrument cluster illumination switch.
Number plate lamps.
Engine compartment illumination.
Illumination for control switches, instrument cluster, cigarette lighter, heater
controls.
Side-markers (L.H.).
Side-markers tell-tale.
F11 (7.5 A) Lamps relay. Side-markers (R.H.).
F12 (7.5 A) Dipped beam (R.H. headlight)
F13 (7.5 A) Dipped beam (L.H. headlight)
F14 (7.5 A) Main beam (L.H. headlight)
F15 (7.5 A) Main beam (R.H. headlight)
F16 (15 A) Instrument cluster.
Turn-signal lamp and hazard flasher relay-interrupter (in turn signal indica-
tion mode).
Low oil pressure tell-tale.
Alternator excitation winding (at engine cranking).
Injection vehicles feature three fuse boxes installed on a bracket behind the instru-
ment panel console. Each fuse is rated for 15A. Circuits protected by these fuses are
listed in table 4.
Table 4
Circuits protected by fuses
Fuse Protected circuit
Upper (15 A) Fuel pump relay (contacts).
Fuel pump.
Injectors.
Middle (15 A) Radiator fan motor activation relay (winding).
Canister purge valve*.
Mass airflow sensor.
Vehicle speed sensor.
Heated oxygen sensor* (heater).
Lower (15 A) ECM.
Ignition module.
Inserted fuses (supplied with the harness)
8 A Rear fog light relay.
Rear fog light.
16 A Seat heater.
16 A Central door lock control.
Central door lock motor.
