Page
24
B
Backup
E
Enter
C
Change
F
Function
M
Mode
P
Print
S
Step
T
Tank/Sensor
KEY SYMBOLS:
You can run a PLLD test on all lines or on a single line.
TO START A PLLD TEST
In the Operating mode, press
until the display shows:
Press and the display shows
:
Press to accept all lines. To select a single line, press until
you see the line you want, then press and . The display
below appears:
F
START LINE PRESSURE TEST
PRESS <STEP> TO CONTINUE
consoles\qh\US\plld1.eps
S
SELECT LINE
ALL LINES
consoles\qh\US\plld2.eps
S
C
E
S
SELECT TEST TYPE
3.0 GPH
consoles\qh\US\plld3.eps
This step lets you select 3.0, 0.2, or 0.1 gph line leak tests to run on
the selected line(s). If your system does not have 0.2 or 0.1 gph test
options, you will not see these selections.
To select 3.0 gph test, press . Press to select 0.2 or 0.1 gph
tests, then press . To select the 3.0 gph test, press . The
displays shows:
To run the selected test, press . The system displays the
message (in this example for all lines):
S
C
E
S
3.0 GPH
PRESS <STEP> TO CONTINUE
consoles\qh\US\plld4.eps
S
START LINE TEST: ALL LINE
PRESS <ENTER>
consoles\qh\US\plld5.eps
Pressurized Line Leak Detection Tests (PLLD Option)
