6-1
6 Diagnostics
The Diagnostic main screen gives you access (depending on installed features) to the site's current and historical
tank and line test results. Also from Diagnostic screens, you can manually run tank tests, PLLD line tests and view
technical data from monitored devices. Touch the Help button at the top of each diagnostic screen to view more
information on each screen’s contents.
From the Home Screen, touch the Diagnostics button to access the Diagnostics Main screen. To access specific
diagnostic information for the TLS-450, touch the desired diagnostic button. An overview of each diagnostic
component is discussed in the paragraphs below.
Tank Test
The Tank Test diagnostics contain information on all environmental tank tests. Each report has quick access to the
appropriate tank test setup screen. Manual tank leak tests are run from this diagnostic.
CSLD and/or SLD tabs will be displayed only if these features are supported and at least one tank has the
respective feature enabled. Current or active reports will not be visible for tanks that are not configured or inactive.
Historic reports will be available for tanks even if they are not configured or if they are inactive.
Section 10 of this manual is devoted to CSLD/SLD troubleshooting.
AVAILABLE TANK TEST DIAGNOSTIC REPORTS
•
CSLD Test Status Report (current CSLD test status)
• CSLD Rate Table Report (CSLD rate table)
• CSLD Monthly Report (CSLD state changes)
• SLD Last Test Report (most recently completed SLD tests)
• SLD In-Progress Reports (SLD active tests)
• SLD History Report (all SLD test results)
PLLD
The PLLD Diagnostics provide access to the PLLD Manual Test interface and all PLLD diagnostic reports. Each
report has quick access to the PLLD setup screen.
Current or active reports will not be visible for PLLD Lines that are not configured or inactive. Historic reports will
be available for PLLD lines even if they are not configured or if they are inactive, as long as they have data to
display.
AVAILABLE PLLD REPORTS AND DIAGNOSTIC SCREENS
•
PLLD Status Report (general status and diagnostic information about PLLD)
• PLLD Manual Test (start or stop PLLD tests manually for one or all lines)
• 3.0 gph (11.3 lph) Tests Report (3.0 gph diagnostics test results)
• Mid-Range Tests Report (mid-range Diagnostics Test Results)
• No-Vent Aborts Report (No-Vent Test Aborts Information)
