2 System Description
System Parts Identification
2-2
Figure 2-2. Printer door assembly
2
1
3
4
consoles\450\918-3.eps
5
LEGEND
Item Description Item Description
1 Paper roll release lever 4 Connector for data input cable to JUSB1 on
CPU board
2 Printer assembly 5 Paper cover
3 Connector for power input cable to J1 on Power
Supply board
