Veeder-Root TLS-4 Series User Manual

2-1
2 System Description
System Parts Identification
The following figures identify the components and printed circuit boards of the TLS-4XX Series consoles.
Figure 2-1. Console Front Panel
123
consoles\450\918-1.eps
LEGEND
Item Description Item Description
1 Optional integral printer (Printer Door
Assembly)
3 Touch screen (Display Door Assembly)
2 LED Status indicators
Green LED - System Normal
Yellow LED - Active Warning
Red LED - Active Alarm
