Preparing The TLS-450 Console For Upgrade Removing The CPU Board
4. Tilt the board a little away from the bulkhead (item 2 in Figure 8) and grasping the edge of the board pull out
firmly t
o remove the board from its backplane board connector. Once the CPU board is free from t
he
conn
ector, slowly remove the board from the console being careful not to hit the CF card against the door.
5. Place the TLS-450 CPU board on a clean work surface. Locate the iButton on t
he TLS-450 CPU board. This
component
will be transferred to the new TLS-450PLUS CPU board.
Figure 9. Locating TLS-450 CPU Board Reusable iButton
