11 Supplement
MINITRAC 31 • Foundation Fieldbus
41782-EN-211203
Electromechanical data - version IP66/IP67
Options of the cable entry
Ʋ Cable entry M20 x 1.5; ½ NPT
Ʋ Cable gland M20x1.5;½NPT(cablediameterseebelowtable)
Ʋ Blind plug M20 x 1.5; ½ NPT
Ʋ Closing cap ½ NPT
Material ca-
ble gland
Material seal
insert
Cable diameter
4.5 … 8.5 mm 5 … 9 mm 6 … 12 mm 7 … 12 mm 10 … 14 mm
PA NBR – ● ● – ●
Brass, nickel-
plated
NBR
● ● ● – –
Stainless
steel
NBR
– ● ● – ●
Flammability class - Supply lines atleastVW-1
Wirecross-section(spring-loadedterminals)
Ʋ Massivewire,strandedwire 0.2…2.5mm²(AWG24…14)
Ʋ Strandedwirewithendsleeve 0.2…1.5mm²(AWG24…16)
Integrated clock
Date format Day.Month.Year
Time format 12h/24h
Timezone,factorysetting CET
Max. rate deviation 10.5min/year
Additional output parameter - Electronics temperature
Output of the temperature values
Ʋ Analogue Viathecurrentoutput
Ʋ Digital Viathedigitaloutputsignal(dependingontheelectron-
icsversion)
Range -40…+50°C(-40…+122°F)
Resolution <0.1K
Accuracy ±5 K
Voltage supply
Operating voltage
Ʋ Sensorpowersupply 24…65VDC(-15…+10%)or24…230VAC
(-15…+10%),50/60Hz
Ʋ FF bus 9…32VDC
Electrical protective measures
Application area Outdoor areas
Altitude above sea level 2000m(6561ft)
