10 Adjustment menu
VEGAPULS C 21 • Modbus and Levelmaster protocol
58343-EN-200806
10 Adjustment menu
10.1 Menu overview
Menu item Selection Basic settings
Measurement loop
name
Alphanumeric characters Sensor
Application liquid Storage tank, agitator tank, dos-
ing tank, pumping station/pump
shaft,rainoverowbasin,tank/
collection basin, plastic tank
(measurement through tank
top), mobile plastic tank (IBC),
level measurement in waters,
owmeasurementume/over-
ow,demonstration
Storage tank
Application bulk solid Silo (slim and high), bunker
(large volume), stockpile (point
measurement/proledetection),
crusher, demonstration
Silo (slender and
high)
Units Distance unit of the device
Temperature unit of the instru-
ment
Distance in m
Temperature in °C
Adjustment Max. adjustment (distance A)
Min. adjustment (distance B)
Max. adjustment
15,000 m
Min. adjustment
0,000 m
Menu item Selection Basic settings
Damping Integration time
0 s
Linearisation Linearization type Linear
Scaling Scaling size
Scaling unit
Scaling format
0 % correspond to 0 l
100 % correspond
to 100 l
Display Menu language
Displayed value
Backlight
-
Filling height
On
Access protection Bluetooth access code -
Protection of the parameteri-
zation
Deactivated
False signal sup-
pression
False signal suppression
0 m
Sounded distance to the me-
dium
0 m
Reset Delivery status, basic settings -
Main menu
Extended functions
