Vega VEGAPULS C 21 User Manual

50
14 Supplement
VEGAPULS C 21 • Modbus and Levelmaster protocol
58343-EN-200806
14.4 Setup
Register Num-
ber
Register Name Data type CongurableValues Unit Default
Value
3000 Byte Oder (Floating point
format)
enum8
r/w
0=ABCD, 1=CDAB,
2=DCBA, 3=BADC
– 0
3200 Distance unit enum16
r/w
44=ft, 45=m, 47=in,
49=mm
- m
3201 Temperature unit enum16
r/w
32=°C, 33=°F, 35=K - °C
3401 Min.-Adjustment oat32
r/w
0 ... Measurement range - 0
3403 Max.-Adjustment oat32
r/w
0 ... Measurement range - Measure-
ment range
3600 Medium type enum16
r/w
0=Liquids, 1=Solids - Liquids
3601 Application liquid enum16
r/w
0 =Storage tank, 1=
Storage tank (product ag-
itation), 2=Cargo tank,
3=Reactor tank, 4=Dos-
ing tank, 5=Stilling pipe,
6=Bypass, 7=Outside of
plastic tank, 8=Outside
of mobile plastic tank,
9=Level of open water,
10=Openume,11=Water
weir, 12=Demonstration,
13=Pump station, 14=Col-
lection tank
- Storage
tank
3602 Application solid enum16
r/w
0=Silo, 1= Bunker Big,
2=Bunkerfastlling,
3=Prolregistrationheap,
4=Breaker mill, 5=Demon-
stration
- Silo
14.5 Measured values
Register Number Register Name Data type
Access
Note
100 Status enum8
ro
Bit 0: Invalid Measurement Value PV, Bit 1: Invalid Meas-
urement Value SV, Bit 2: Invalid Measurement Value TV, Bit
3: Invalid Measurement Value QV
104 PV Unit enum16
ro
32=Degree Celsius, 33=Degree Fahrenheit, 40=US Gal-
lons, 41=Liters, 42=Imperial Gallons, 43=Cubic Meters,
44=Feet, 45=Meters, 46=Barrels, 47=Inches, 48=Centim-
eters, 49=Millimeters, 111=Cubic Yards, 112=Cubic Feet,
113=Cubic Inches
106 PV oat32
ro
Primary Variable in Byte Order CDAB
