Vega VEGAPULS C 21 User Manual

52
14 Supplement
VEGAPULS C 21 • Modbus and Levelmaster protocol
58343-EN-200806
Register Number Register Name Data type
Access
Note
2008 QV oat32
ro
Quarternary Variable in Byte Order ABCD (Big Endian)
2100 Status enum8
ro
See Register 100
2102 PV oat32
ro
Primary Variable in Byte Order DCBA (Little Endian)
2104 SV oat32
ro
Secondary Variable in Byte Order DCBA (Little Endian)
2106 TV oat32
ro
Third Variable in Byte Order ABCD DCBA (Little Endian)
2108 QV oat32
ro
Quarternary Variable in Byte Order DCBA (Little Endian)
2200 Status enum8
ro
See Register 100
2202 PV oat32
ro
Primary Variable in Byte Order BACD (Middle Endian)
2204 SV oat32
ro
Secondary Variable in Byte Order BACD (Middle Endian)
2206 TV oat32
ro
Third Variable in Byte Order BACD (Middle Endian)
2208 QV oat32
ro
Quarternary Variable in Byte Order BACD (Middle Endian)
14.6 Additional measurement data
Register Number Register Name Type Note/Unit
2303 Measured distance oat32
ro
Distance from the sensor to the liquid surface (m)
2305 Absolute echo am-
plitude
oat32
ro
dB
2314 Signal Quality oat32
ro
dB
14.7 Diagnosis data, device information
Register Number Register Name Type Note
2300 Current diagnos-
tic code
uint32
ro
According to NAMUR NE 107 recommendation
2307 Device status uint8
ro
Current event category: 0 = ok, 1 = failure, 2 = check, 4 =
maintenance, 8 = out of spec
