第10 页/共 27页
③ 3.5 inch FSTN LCD screen combines positive and negative mode display
4.3 Func
tion interface introduction
Boot interface and basic function interface
Boot logo interface is displayed for 3 seconds after display is turned on. When the communication
connection is established, display enters the main interface, showing real-time information stored in
the controller and battery BMS according to the communication protocol. (Battery indicator will not
show battery percentage if BMS info is not available)
*When RTC and Auto Light functions are included in chosen product, the main funtion
interface will display real time clock and enter into auto light setting by default.
Other functions indication
TRIP info and related info indication
Subtotal mileage TRIP is displayed next to sign with five , reserving one decimal place.
After exceeding 9999.9, the decimal point is not displayed, with the maximum value of 99999. After
exceeding the maximum value 99999, the displayed number is the actual TRIP data minus 100000.
When switching the subtotal mileage interface, the average speed AVG SPEED is displayed in
the speed display area, with the maximum value of 99.9.
Statistics of riding usage time of subtotal mileage is displayed on the bottom right, as shown in the
following picture:
Basic interface
Hangzh
ou VeloFox Intelligent Technology Co,. Ltd.
Ver.
1.02
