product is mid-mount on the horizontal tube with a handlebar size ofφ22.2mm, φ25.4mm, φ
31.8mm. The remote control is left mounted on the horizontal tube with a handlebar size ofφ22.2mm,
φ23.8mm.
5. Display coding rules
As shown in above picture:
Product model
Hardware version number，C-CAN, U-UART, last 2
numbers
are
version
M
anufacture factory code
，
M0, M1
，
M2, M3
M
anufacture year and week number
P
roduction serial number
82.6mm
70.1mm
3.5”LCD
Holder size ： φ 22.2mm ， φ
25.4mm，φ31.8mm
Hangzh
ou VeloFox Intelligent Technology Co,. Ltd.
Ver.
1.02
