TRIP value has 4 digits, including one digit after the decimal point. After 9999.9 KM is exceeded,
the decimal point is not indicated, and a 5-digit mileage value is displayed directly, with a maximum
value of 99999km. After the maximum value is exceeded, the value is shown as the actual mileage
value deducted by 100,000.
Cycling statistics in the basic function interface can be displayed in the main interface, and the
data can be cleared by pressing the button. During data clearing, only TRIP related information is
cleared, but ODO accumulated mileage information is not cleared.
Other function interfaces
Function interface I-battery information,
The function interface II mainly displays battery information, including voltage, capacity
percentage, accumulated charging cycles, and Range which is endurance mileage.Accumulated
charging cycles are provided by battery BMS, if it is not available from BMS, display shows ---- for
charging cycles. The Range is calculated by controller using battery BMS capacity info, if controller
can not provide range info, range info shows----.
Function interfaceⅡ——Motor information
Function interfaceⅡshows the motor information of the system. The function needs the support
of the controller.
Power analysis area shows power output analysis, including average power output by motor, the
maximun output by motor, and power output shared between rider and motor. Power output by motor
will follow data provided by controller, if requested info is not available from controller, display will
calculate using collected voltage and electric currents data.
