Coded Channels
The VR60 receiver can identify four transmitter types on one frequency. This is done by using
different sync and bin values on four different channels, referred to as a coded map. The default
values assigned to each channel are shown in the table below. The coded map specific to this order
is found in the Appendix. The channel values differ depending on the frequency range so as to best
fit the transmitter capabilities based on transmitter size and power.
VEMCO Default Coded Map “D”
Model Frequency
Band
Channel Code Type
# Sync
(ms)
Bin
(ms)
Description Transmitter
Abbr.
V8, V8B,
V8SC, V16,
V16T, V16P
51 - 78 kHz
(Blank = 300)
A 401.2 22.3 256 Pinger R256
B 380 20 4K Pinger R04K
C 360 20 256 Sensor S256
D 340 20 64K Pinger R64K
V22, V22T,
V22P
30 - 50 kHz
(Blank = 650)
A 800 30 256 Pinger R256
B 770 30 4K Pinger R04K
C 740 30 256 Sensor S256
D 710 30 64K Pinger R64K
V32, V32T,
V32P, Chat
27 - 34 kHz
(Blank = 750)
A 1000 40 256 Pinger / Chat R256
B 960 40 4K Pinger R04K
C 920 40 256 Sensor S256
D 880 40 64K Pinger R64K
