V11 DIRECTIONAL HYDROPHONE (25-35kHz)
OPERATING
FREQUENCY:
25 to 35 kHz.
OPERATING DEPTH: 5 meters.
POWER SUPPLY: 12 VDC 5 mA (supplied by receiver).
DIMENSIONS: 116 mm x 184 mm x 57 mm
CASE MATERIAL: Machined solid block of Aluminum.
CABLE: 6.5mm diameter polyurethane jacket, twisted shielded pair. Standard
length 10 meters, extra length available with Option 04.
CONNECTOR: AMPHENOL MS-3106A-10SL-3S.
APPLICATION: The V11 is used for directional tracking. It can be deployed on a hull
mount, strut mount, or on a V-Fin towed depressor.
FREQUENCY (kHz) 27 32
SENSITIVITY (dB re 1V/uPascal @ 1m) -145 -143
NOISE FLOOR (dB re 1 uPascal/SqrtHz) 37 35
HORIZONTAL ACCEPTANCE ANGLE - BANDWIDTH
(degrees, between 3 dB points)
24 20
VERTICAL ACCEPTANCE ANGLE - BANDWIDTH (degrees,
between 3 dB points)
150 150
