Vendo VUE 30 Manual

T-8
04/2005
ERROR DESCRIPTION OF
ERROR CODE
CHECKING METHOD CORRECTIVE ACTION
Accept Disconnect Disconnected acceptor --
indicates that an acceptor is unplugged.
Check coin mechanism plugs. Check for faulty harness wiring (see wiring diagram for circuit).
Correct connections.
Routing Coin routing - indicates a coin
was routed incorrectly
.
Verify acceptor set-up using manufacturer’s recommendations. If acceptor was set up correctly, replace acceptor.
Dollar Bill Validator Bill Validator Communication
Bill validator communications - No bill validator communication for 5 seconds.
If changer or card reader is being used, check for “CC” or “rC” errors.
If there are no “CC” or “rC” errors: 1) Check bill acceptor harness; 2) Replace bill acceptor. If there is a “C” or “rC” error: 1) Check control
board MDB harness.
Turn off door switch and wait at least five seconds. Turn on door switch.
Bill V
alidator Full Bill validator full - reported
by validator (ST
ACKER
command).
Insure bill cashbox is empty and that the cashbox is properly closed and in place.
If cashbox appears to be OK, replace bill acceptor.
Bill Validator Motor Bill validator motor is reported
as defective by validator
.
No test available Replace bill acceptor.
Bill Validator Jammed Bill jammed -- reported by
validator
.
Check bill validator for obstructions or dirt. If no obstructions are apparent, replace bill validator.
Bill Validator ROM Bill validator check sum is
incorrect.
Turn power switch off. Wait at least five seconds. Turn power
switch on. Manually clear the error.
If error does not clear, replace bill acceptor.
Bill Validator Open Bill validator is open. Check that bill cashbox is closed and in correct position. If cashbox appears to be OK, replace bill acceptor
.
Bill Validator Sensor Bill validator sensor is not
functioning.
Check bill validator for obstructions or dirt. If no obstructions are apparent, replace bill validator
.
Card Reader Card Reader Communication
There is no card reader communication for 5 seconds.
If card reader/bill acceptor is being used, check for “rC’ or “bC”
errors.
If there is no “rC” or “bC” error: 1) Check changer harness. 2) Replace changer.
Turn power switch off. Wait at least five seconds. Turn power switch on.
If there is a “rC” or “bC” error: 3) Check control board MdB harness.
Card Reader Most recent “non-transient
error” from the card reader
.
No test available. Refer to card reader manual for corrective action.
Refrigeration Temp Sensor The temperature sensor is
defective or unplugged.
Check to see that temperature sensor harness is plugged into door harness at air dam area.
If the sensor is unplugged, replug it.
Check for temperature sensor connection J7 on control board is plugged in.
If the connection is unplugged, replug it.
Compressor System has failed to
decrease temperature 1° per hour while the compressor is running.
Check refrigeration settings (refer to refrigeration section of programming manual).
Change settings as required.
Check if evaporator is frozen. Check seal around cabinet. Verify evaporator fan is running.
Check harness to fan motor and check output voltage.
Miscellaneous Problems Door Switch Outer door has been open for
more than one hour.
Check the vendor’s door switch to see if it’s sticking or miswired. Replace the door switch, if defective.
