Press

MODE/

I2 00

COOL

I2 00

HEAT

I2 00

OFF

MODE/

NOTE: when the thermostat is in the OFF mode, you may turn the

thermostat back on by pressing the MODE/NEXT, UP, or DOWN

buttons.

Selecting the Heat or Cool Mode

The HEAT setting indicates the

temperature the room has to

reach before the furnace will

turn on to heat the room.

Heating Only

The COOL setting indicates the

temperature the room has to

reach before the air conditioner

will turn on to cool the room.

Cooling Only

OFF indicates both heating

and air conditioning

systems are turned off.

Off

Select Mode by Pressing the MODE Button

Time Schedule for

Heating or Cooling

The WAKE or SLEEP setting will

activate the time period prog-

ramming for the cooling or

heating setpoint ONLY.

I2 00

COOL

WAKE

Page 6
