Venstar TSTATEZ User Manual

Advanced Setup
Continued
NOTE: Each step # is located
at the bottom right
corner of the display
for easy reference.
Select whether the
thermostat will be heat
only, cool only, or heat
and cool.
Press the MODE/NEXT button.
While holding the MODE/NEXT,
press the PROGRAM ON/OFF
button to enter Setup
screens.
PROGRAM
ON / OFF
MODE/NEXT
2
3
COOL
4
O
5
YES
NO
Press
Press
Press
Press
MODE/NEXT
MODE/NEXT
MODE/NEXT
MODE/NEXT
HEAT
Select backlight operation:
YES - Light continuously
NO - Light for 8 seconds
after a button press
YES = Heat Pump
operation
NO = Gas Electric
operation
Select the reversing valve
polarity for Heat Pump
operation:
O = Energize in cooling
b = Energize in heating
(Step 5 only appears if
heat pump is on in step 4)
O
b
Page 10
YES
NO
