Ventacity Systems VSCM Series - Dimensions

7
Rev. 01.01
SPECIFICATIONS
2. SPECIFICATIONS
2.2 DIMENSIONS
a
b
B
K
k
18
2x1/2"
C
D
c
d
h
i
j
H
x z
X
Z
Y
y
INDOOR ENVIROMENT
OUTDOOR ENVIROMENT
a
b
B
K
k
18
2x1/2"
C
D
c
d
h
i
j
H
x z
X
Z
Y
y
INDOOR ENVIROMENT
OUTDOOR ENVIROMENT
UNIT H h a B b i j K k c d C D X x Y y Z z
VS250 CM
30.7
26.4 46.9 12.2 11.8 44.1 27.6 19.1 0.8 9.8 5.9 10.8 6.9 6.5 6.5 13.1 13.1 6.5 6.5
VS400 CM
42.5 38.2 55.1 12.2 11.8 52.4 39.4 23.2 0.8 11.8 7.9 12.8 8.8 9.5 9.5 20.4 20.4 9.5 9.5
VS900 CM
54.5 50.0 66.9 15.4 15.0 64.2 51.4 28.3 0.8 19.7 9.8 20.6 10.8 12.7 12.7 24.6 24.6 12.7 12.7
VS1200 CM
67.3 63.0 78.7 18.5 18.1 56.3 64.2 35.5 0.8 23.6 11.8 24.6 12.8 17.0 17.0 28.9 28.9 17.0 17.0
a
b
B
K
k
18
2x1/2"
C
D
c
d
h
i
j
H
x z
X
Z
Y
y
INDOOR ENVIROMENT
OUTDOOR ENVIROMENT
INDOOR
OUTDOOR
0.71" OD (Condensate)
1/2" Flex-Conduit
Connector (Mains)
