Choose OPTION 1 or OPTION 2 below depending on the battery pack to be attached.
OPTION 1: Attaching the Li-ion Battery Kit and its Compatible Suspender Clip Components.
1 To properly place the Li-ion battery kit, align its contacts with the monitor’s contacts, at the monitor
bottom.
2 To secure the battery kit to the monitor, tighten the four captive screws on the kit bottom.
3 Open the suspender clip.
4 Place the washer on the screw.
5 Insert the screw with washer through the clip’s center hole and into the screw hole on the monitor. Be
sure the clip’s ring is at the top of the monitor.
6 Tighten the screw.
OPTION 2: Attaching the Extended Range Li-ion (or Alkaline) Battery Pack and its Compatible
Suspender Clip Components.
If inserting the Alkaline battery pack, follow steps 1-14.
If inserting the Extended Range Li-ion battery pack, follow steps 5-14 ONLY.
1 To prepare the Alkaline battery pack, unlatch and lift the hinged portion of the battery pack.
2 If needed, remove and set aside any spent batteries from within the pack.
3 Insert new batteries so that their negative contacts are in contact with the springs inside the pack. DO
NOT MIX BATTERY TYPES.
4 Close the latch. A click sounds.
5 To properly place the Extended Range Li-ion (or Alkaline) battery pack inside the battery cover, ensure:
the battery circuitry is exposed and faces the user;
a small groove at the back of the battery bottom fits over the small rib at the back of the pump
module bottom.
NOTE: each of these two battery packs easily fits within the battery case. If the battery does not easily insert, stop to
ensure proper placement as noted above.
6 To properly attach the cover containing the Extended Range Li-ion or Alkaline battery pack, ensure the
battery contacts are showing at the bottom of the monitor.
7 To secure the battery cover (and its enclosed battery pack) to the monitor, tighten the four captive
screws on the battery cover.
8 Place the monitor face down.
9 The spacer for the suspender clip has one flat end. Place the spacer on the monitor’s case back so its
flat end meets top edge of the battery cover; the hole in the spacer aligns with the screw hole on the
monitor.
10 Open the suspender clip.
11 Place the washer on the screw.
12 Insert the screw with washer through the clip’s hole and through the center hole on the clip back.
13 Place the clip on top of the spacer, inserting its screw into the spacer’s hole and ensuring the clip’s ring
is at the top of the case back.
14 Grasp the clip and spacer with one hand. With the other hand, tighten the screw with the Phillips
screwdriver.
