Ventis™ MX4 Product Manual
© 2014 Industrial Scientific Corporation
46
5 = INMETRO
17148313-Y Extended Range Lithium-ion Battery Pack
Y = Approvals where:
1 = UL, CSA, ATEX, IECEx, INMETRO, GOST-R, GOST-K, KOSHA, MED, and SANS
2 = MSHA
3 = China Ex
4 = ANZEx
17150608 Alkaline Battery Pack: UL, ATEX, IECEx, ANZEx, and INMETRO approvals (CSA, China KA
and China MA approved for diffusion monitor only.)
Conversion Kit** for the diffusion monitor.
NOTE: For use in converting an aspirated monitor with a rechargeable Extended Range Lithium-ion battery pack to a diffusion monitor with a
rechargeable Extended Range Lithium-ion (or Alkaline) Battery Pack. (Batteries sold separately.) Kit parts listed below can be ordered separately as
replacement parts.
**17151184-XY Cover, Extended Range Lithium-ion or Alkaline
X = Cover Color, where: 0 = Black, 1 = Orange
(captive screw torque value: 55 oz-in or .39 n.m . +/- 10%)
Y = Approvals where:
1 = UL, CSA, ATEX, IECEx, GOST-R, GOST-K, and KOSHA; MED (Lithium-ion only)
2 = MSHA (Extended Range Lithium-ion only)
3 = China Ex
4 = ANZEx
5 = INMETRO
C = China KA
**17152506 Suspender Clip Spacer
**17120528 Suspender Clip
**17153137 Locking Washer
** 17152507 Screw, Phillips
MONITOR SPECIFICATIONS
Item Description
Display Backlit Liquid Crystal Display (LCD)
Buttons Two (ON/OFF/MODE and ENTER)
Monitor case Polycarbonate with ESD protective rubber overmold
Alarms Ultra-bright LEDs, loud audible alarm (95dB at 30 cm), and vibrating alarm
Size and Weight Diffusion with Lithium-ion (typical)
spirated with Extended
ange
Lithium-ion (typical)
Size 103 mm x 58 mm x 30 mm
(4.1” x 2.3” x 1.2”)
172 mm x 67 mm x 66 mm
(6.8” x 2.6” x 2.6”)
Weight 182 g (6.4 oz) 380 g (13.4 oz)
OPERATING CONDITIONS
Warm-up time 40 seconds (includes stabilization time)
Temperature range -20 °C to +50 °C (-4 °F to +122 °F)
Humidity range
15–95% relative humidity (RH) noncondensing (during continuous operation)
Pressure range 1 atm ±20%
